Hakko Electronics Monitouch V7 - Page 241

5-34 3. SHARP PLC
RS-422
Wiring Diagram 3
Wiring Diagram 4
Wiring Diagram 5
FG
−SD
+RD
−RD
1
13
24
25
+TXD
−TXD
−RXD
10
11
13
V7 (CN1)
D-sub 25pin(Male: )
+SD 12
+RXD 12
PLC
D-sub 15pin(Male: )
* Use shielded twist-pair cables.
D-sub 25-pin (male)
D-sub 15-pin (male)
FG
−SD
+RD
−RD
1
13
24
25
L1
L2
L4
V7 (CN1)
D-sub 25pin(Male: )
+SD 12
L3
GND
PLC
* Use shielded twist-pair cables.
D-sub 25-pin (male)
FG
−SD
+RD
−RD
1
13
24
25
+SD
+RD
−SD
3
9
11
V7 (CN1)
D-sub 25pin(Male: )
+SD 12
−RD 10
PLC
D-sub 15pin(Male: )
* Use shielded twist-pair cables.
D-sub 25-pin (male)
D-sub 15-pin (male)
