5-38 4. HITACHI PLC
HIDIC-S10/2α
HIDIC-S10/ABS
Memory TYPE Remarks
FW (work register) 0
X (input relay) 1 XW as word device
Y (output relay) 2 YW as word device
R (internal relay) 3 RW as word device
G (global link) 4 GW as word device
K (keep relay) 5 KW as word device
T (on-delay timer contact) 6 TW as word device
U (one-shot timer contact) 7 UW as word device
C (up/down counter contact) 8 CW as word device
TS (on-delay timer set value) 9
TC (on-delay timer elapsed value) 10
US (one-short timer set value) 11
UC (one-shot timer elapsed value) 12
CS (up/down counter set value) 13
CC (up/down counter elapsed value) 14
DW (data register) 15
E (event register) 16 EW as word device
S (system register) 17 SW as word device
J (transfer register) 18 JW as word device
Q (receive register) 19 QW as word device
M (extensional internal register) 20 MW as word device
Memory TYPE Remarks
0E 0
06 1
18 2
19 3
1A 4
1B 5
1C 6
1D 7
