5-68 10. KOYO PLC
G-01DM
On-line/Off-line switch: On-line
Short plug 1: open
Short plug 2: RS-232C . . . . ENABLE
RS-422. . . . . . DISENABLE
SW1 DIP switch:
SW2 DIP switch:
No Setting Contents
1ON
Unit No. 1
2OFF
3OFF
4OFF
5OFF
6OFF
7OFF
8OFF1: N
9OFFSlave
No Setting Contents
1ON
Same as that set on V7
Normally 19200 bps
2ON
3ON
4ONWith parity
5 OFF Self-diagnosis
6 OFF Turn-around delay
7OFF
Response delay time 0 msec
8OFF
9 OFF HEX mode
