5-80 11. Allen-Bradley PLC
Wiring Diagram 3
Wiring Diagram 4
Wiring Diagram 5
V7 (CN1)
D-sub 25pin(Male: )
FG
SD
RD
RS
CS
1
2
3
4
5
DCD
RXD
TXD
DTR
1
2
3
4
5
COM
DSR 6
7
8
RTS
CTS
SG 7
PLC
D-sub 9pin(Female: )
* Use shielded twist-pair cables.
D-sub 25-pin (male)
D-sub 9-pin (female)
V7 (CN1)
D-sub 25pin(Male: )
FG
SD
RD
RS
CS
1
2
3
4
5
RXD
PLC
D-sub 9pin(Female: )
TXD
DTR
2
3
4
5
COM
SG 7 6
7
8
DSR
RTS
CTS
* Use shielded twist-pair cables.
D-sub 25-pin (male)
D-sub 9-pin (female)
V7 (CN1)
PLC
D-sub 25pin(Male: )
D-sub 9pin(Male: )
FG
SD
RD
RS
CS
SG
1
2
3
4
5
7
RD
SD
RS
2
CD 1
3
4
GND 5
DR 6
RS 7
CS 8
Micro
Logix
1000
* Use shielded twist-pair cables.
A •B’s
RS-232C
Ladder transfer
cable
D-sub 25-pin (male)
D-sub 9-pin (male)
