10. DIP Switch Setting 1-27
Hardware Specifications
CF Auto Load (DIPSW1)
A screen data file saved on a CF card can be auto-loaded as described below.
1. Transfer screen data from the computer to a CF card. (Refer to the Reference Manual
for more information.)
2. Set DIPSW1 in the ON position, and insert the CF card that contains the screen data
file.
3. Turn the V7 unit on. The screen data is automatically loaded into the FLASH memory
of the unit.
To Next Page
