Haldex EB+ Gen3 - Supply Switch Test Box Circuit Diagram; Mains Power Supply Circuit Diagram

EB+ Gen3Installation guide
1032013 Innovative Vehicle Solutions
Pin 5
Pin 1
Pin 2
Pin 3
Pin 4
Circuit
breaker
Warning
lamp
switch
Warning lamp
24V 2.8W
ISO7638
ABS
Connector
Pin 4
Pin 1
ISO12098 /
ISO1185 (24N)
Connector
ISO7638
Switch (B+ Ign)
ISO 7638
(B+P)
ISO12098 /
ISO1185 (24N)
Switch (B+I)
8-32 volts
B+
B-
To ensure correct operation of the
‘Supply switch test box’ the B- connection
must be connected to the trailer chassis.
+
-
Warning lamp
24 V 2.8 W
Warning lamp
switch
ISO 7638
(B+P)
ISO 7638
switch (B+ ign
ISO 7638
ABS connector
ISO 12098 /
ISO 1185 (24N)
switch (B+I)
Circuit
breaker
8-32 volts
B+
Pin 5
Pin 1
Pin 2
Pin 3
Pin 4
B-
-
+
ISO 12098 /
ISO 1185 (24N)
connector
Pin 4
Pin 1
To ensure correct operation of the ‘supply switch test box’ the
B- connection must be connected to the trailer chassis.
+24V
0V
25A Bridge
rectifier
3A fuse
110V
or
240V AC
200VA
20 sec
4 capacitors
10,000 uF
each 40V DC
at 2A ripple current
+
+
A
B
C
D
Connect A to C and B to D for 110V operation
Connect B to C for 240V operation
-
3 A fuse
25 A bridge
rectifier
4 capacitors
10, 000 uF
each 40 V dc
at 2 A ripple current
110 V
or
240 V ac
A
- +
+
+ 24 V
0 V
B
C
D
200 VA
20 sec
Connect A to C and B to D for 110 V operation
Connect B to C for 240 V operation
Supply switch test box circuit diagram
Mains power supply circuit diagram
