Haldex EB+ Gen3 - Semi & Centre Axle Trailers - Side by Side (Sxs); System Configurations

EB+ Gen3Installation guide
152013 Innovative Vehicle Solutions
2.1
2.2
EPRV’S
ISO
connector
end
Key
Notes (applicable to all above diagrams):
› Any axle without directly controlled wheels may be a lift axle
› Any axle may be a steered axle
Semi & centre axle trailers - side by side (SxS)
System congurations
2S / 2M
