Haldex EB+ Gen3 - Aux 1; ECU Connector Identification; Iso 12098; Iso 1185 (24 N); Sensor S1 A

EB+ Gen3 Installation guide
80 Innovative Vehicle Solutions 2013
AUX 1
COLAS
®
Retarder
Trailer lamp
ILAS
®
-E front
ILAS
®
-E rear
AUX power
Steer axle lock
Service lamp
Overload lamp
Remote overload lamp
Stability lamp
General purpose output
TA+
Info Point
Info Point / COLAS
®
Speed lock
TPMS lamp
AUX 4
Lining wear sensor
General purpose input
Control line sensor
Soft Docking
Mechanical height
sensor
Mechanical height
sensor remote
External pressure sensor
AUX 5
Lateral accelerometer
General purpose input
Control line sensor
Soft Docking
Mechanical height
sensor
Mechanical height
sensor remote
External pressure sensor
AUX 2 & 3
COLAS
®
Retarder
Trailer lamp
ILAS
®
-E front
ILAS
®
-E rear
AUX power
Steer axle lock
Service lamp
Overload lamp
Remote overload lamp
Stability lamp
ILAS
®
-E front manual
ILAS
®
-E rear manual
General purpose output
TA+
Speed lock
TPMS lamp
ECU connector identication
Sensor S1B
Sensor S2B
Sensor S1A
Sensor S2A
DIAG+
Interface
Info Centre 2
ISO 7638ISO 12098 /
ISO 1185 (24N)
