Haldex EB+ Gen3 - System Drawing Layout - Steer Axle Lock

EB+ Gen3Installation guide
932013 Innovative Vehicle Solutions
Date Title:
Replacement for:
Steer Axle Lock * (2S/2M **)
06.09.12
Schering
1
2 3 4 5 6 7 8 9
10
Pos. Qty.
Name:
Drawing:
11
Checked Name:
12 13 14 15 16 17 18 19 20 21
Pos.
Qty. Description
Customer
22
Part No.
1
1
2
Power ISO 7638
Description
CustomerPart No.
3
4
AUX3009.00
5
478910
11121415
2 Sensor Cable 3m
814 004 401 -
1 EB+ Modulator
823 008 001 -
1 ISO 7638 Cable 12m
814 003 102 -
1 SAUX Cable 6m
814 002 301 -
1 AUX Cable 7m DIN
814 012 201 -
Example Only
Date
6
ILAS-E Front
2 AUX Cable 1m DIN
814 012 221
-
*) ILAS-E using side of vehicle and cab switch / Steer axle lock using reverse light
Colas
®
RtR
+
-
Air suspension
Return to ride height
RD
(+)
BK
(-)
RD
(+)
BK
(-)
7
Signal < 5 s = Traction Assist Signal > 5 s = Lift axle OFF
1 Switch / Cable 7m
815 040 001
-
Lock
1
2
3
6
YE BN GN BK RD WH
RD
(+)
BK
(-)
Steer axle
locking device
**) 4S/3M recommended by Haldex
RD
YE
Super Aux WH – Ground (B-) RD – Stop Light YE – Input A BN – Input B GN – Input C BK – Output 24V
Light System / ISO 12098 4 – Ground (B-) 7 – Stop Light 8 – Reverse Light 9 – Supply (B+) 10 – Wear Control (free) 11 – Trailer Brake Control 12 – Traction Assist 14 – no allocation 15 – no allocation
System drawing layout - steer axle lock (2S / 2M)
