Haldex EB+ Gen3 - 2 M, Side by Side with Trcm; Piping Layout - 2 M Brake

EB+ Gen3 Installation guide
48 Innovative Vehicle Solutions 2013
Item Description Notes
1 Emergency coupling Combined coupling & filter available
2 Service coupling Combined coupling & filter available
3 Pipe filter
4 TrCM
+
5 Air reservoir - brake
6 Drain valve
7 Test point
8 EB+ Gen3 assembly
9 Spring brake chamber
10 Single diaphragm brake chamber
11 Test point simulator
12 Suspension bellows
Piping layout – 2M brake
2M, side by side with TrCM
+
Key
1
Port number
1
Components
Note:
EB+ Gen3 should be supplied with clean / dry air.
7
1
1
1 3
2
23/24/25
4
4
21
1
2 3
2
2
1-2
10
7
7
9 9
11 12
11
12
11
10
9
9
11 12 11 12
4
22
21
21
41
23
23
22
11
23
22
AUXs
12
1
6
5
6
5
11
21
23
1
12
8
11
