EB+ Gen3 Installation guide
104 Innovative Vehicle Solutions 2013
B
A
BLACK (-)
RED (+)
BLACK (-)
RED (+)
A (-)
Common
B (+)
Output
A (-)
Common
B (+)
Output
Checking position Measure between Correct value Remarks
Sensor output A B 0.2 AC Min
Sensor 1A, 1B or 2A, 2B
Sensor disconnected from ECU
Wheel rotated at 1 rev / 2 sec.
Sensor resistance A B 1.0 < AB < 2.4 K
:
Sensor 1A, 1B or 2A, 2B
Sensor disconnected from ECU
Earth continuity resistance
ECU / EPRV
Bracket and chassis
0
:
0 < R < 5 :
COLAS
®
+ - 180 < R < 215 : Cable disconnected
ILAS
®
-E solenoid resistance + - 180 < R < 215 : Cable disconnected
Multimeter readings
Sensor connector
Earth continuity
COLAS
®
connector ILAS
®
-E connector
COLAS
®
DIN connector
ILAS
®
-E Din connector
0 5:
