Haldex EB+ Gen3 - 2 M, Levelling Valve and COLAS

EB+ Gen3 Installation guide
54 Innovative Vehicle Solutions 2013
Item Description Notes
1 Air suspension supply Air supplied from TrCM
+
, TEM
®
or separate pressure protection valve
2 Air suspension reservoir
3 Drain valve
4 Pipe filter
5 Levelling valve
6 Suspension bellows
7 Test point
8 EB+ Gen3 assembly
9 Test point simulator
10 COLAS
®
+
2M, levelling valve and COLAS
®
Key
1
Port number
1
Components
Note:
EB+ Gen3 should be supplied with clean / dry air.
+
7
10
9
3
2
6 6 6
6 6 6
21
22
2
1
1
41
8
11
21
22
12
1
4
5
7
1
Air supplied from:
TrCM
+
or
TEM
®
or
separate pressure protection valve
