EB+ Gen3Installation guide
552013 Innovative Vehicle Solutions
Item Description Notes
1 Air suspension supply Air supplied from TrCM
+
, TEM
®
or separate pressure protection valve
2 Air suspension reservoir
3 Drain valve
4 Pipe filter
5 Levelling valve
6 Suspension bellows
7 Test point
8 EB+ Gen3 assembly
9 Test point simulator
10 COLAS
®
11 ILAS
®
-E
+
2M, COLAS
®
and ILAS
®
-E
Key
1
Port number
1
Components
Note:
EB+ Gen3 should be supplied with clean / dry air.
+
7
9
3
2
6 6 6
6 6 6
2122
2
1
1
41
8
11
21
22
12
1
22
11
21
11
10
1
6
5
AUX1
AUX2
4
7
1
Air supplied from:
TrCM
+
or
TEM
®
or
separate pressure protection valve
