Haldex EB+ Gen3 - Page 127

EB+ Gen3Installation guide
1272013 Innovative Vehicle Solutions
Y-splitter 3x2x2 way Length
814 039 001 0.5 m
Y-splitter 3x3x3 way Length
814 039 101 0.5 m
Super AUX cable Length
814 002 301 6 m
814 002 311 12 m
814 002 321 9 m
814 002 331 4 m
814 002 341 1 m
Power B to ISO 15170 Super AUX Length
814 004 301 (4 pole) 1 m
814 004 311 (4 pole) 6 m
L1
L2
Power B to ISO 15170 Super AUX L1 L2
814 029 001 (4 pole) 1 m 1 m
814 029 011 (4 pole) 6 m 5 m
814 029 021 (4 pole) 6 m 1 m
Sensor cable Length
814 004 401 3 m
814 004 411 6 m
814 004 421 2 m
814 004 431 10 m
814 004 441 14 m
814 004 451 8 m
814 004 461 12 m
814 004 471 4 m
