EB+ Gen3Installation guide
732013 Innovative Vehicle Solutions
Blue connector
Identify orientation of the ISO 7638 blue coloured
connector.
Ensure contact pins and seal are clean and free of any
contamination prior to installation.
In position ‘PWR-A’, on the slide lock housing, insert
connector fully home.
Remove the blanking plug from the ‘PWR-A’ position.
PWR-B
PWR-A
