EB+ Gen3Installation guide
772013 Innovative Vehicle Solutions
Yellow connector
Identify orientation of the 3M link cable yellow
coloured connector.
Ensure contact pins and seal are clean and free of any
contamination prior to installation.
In position ‘3M’, on the slide lock housing, insert
connector fully home.
Remove the blanking plug from the ‘3M’ position.
PWR-B
PWR-A
3M
