Chapter 7 VBI
© 2013 Harmonic Inc. Harmonic All rights reserved. 231 Ellipse 3000 Release 3.0, Rev. B
General Sub-Menu/Box
7.1.2 PID Parameter
The PID parameter sets the VBI elementary stream PID number. In the Ellipse 3000 VBI is
extracted only from the video input that is being encoded (active video).
The range is +32 to +8190.
Front Panel:
7.1.3 Activation Parameter
The Activation parameter sets the VBI elementary-stream activation mode.
The available options are:
■ Enabled
■ Disabled (Default)
7.1.4 Teletext Subtitling Activation Parameter
The available options are:
■ Enabled
■ Disabled
PID
+0770
<+0032 - +8190>
