Chapter 4 Transport Stream Configuration
© 2013 Harmonic Inc. Harmonic All rights reserved. 97 Ellipse 3000 Release 3.0, Rev. B
M-SPTS Sub-Menu/Tab
4.3.2 M-SPTS Configuration Management
The M-SPTS stream managing enables you to monitor and configure the following parameters of
a selected M-SPTS transport stream:
■ MSPTS sub-menu/box
❑ Transport Name – The name of the M-SPTS transport (free text).
❑ Add PID and List/Drop PID – Provides access to setting the PID parameters for the M-SPTS
stream (for details, refer to 4.3.2.3 M-SPTS PID Management (Add / Drop PID) on page 102).
■ General sub-menu/box
❑ Protocol – The IP-output interface protocol used by the stream (UDP or RTP)
(FEC Enabled only).
❑ Number of Packets – The number of transport-stream packets per IP frame.
Range 1 to 7. Default: 7.
❑ Transport Name – (FEC Disabled only)
❑ Activation – Status of the stream (Enabled/Disabled) (FEC Disabled only)
❑ Transport Rate – The rate of the stream (Range: 350,000 to 70,000,000) (FEC Disabled only).
❑ Transport ID – The identification number of the stream (Range: 1 to 65535)
(FEC Disabled only).
❑ Network ID – The identification number of the network (Range: 0x1 to 0x65535, hex)
(FEC Disabled only).
❑ Network Name – The name of the network (free text) (FEC Disabled only).
❑ FEC Activation – (FEC Enabled only)
❑ FEC Dimension – (FEC Enabled only)
❑ FEC Column Number – (FEC Enabled only)
❑ FEC Row Number – (FEC Enabled only)
❑ Cascading Included – (FEC Disabled only)
❑ Physical Port Activation – (FEC Enabled only)
■ IP1/IP2 sub-menu/box – Provides access to the stream IP1 / IP2 detailed parameters (for
details, refer to 4.3.2.1 IP1/IP2 Configuration on page 100).
■ Advanced sub-menu/box – Provides access to advanced functions of the stream (for details,
refer to 4.3.2.2 Advanced Stream Functions on page 101) (FEC Disabled only).
■ PID sub-menu/box – (FEC Disabled only)
NOTE: Some parameters only display when FEC Activation and Cascading Included are disabled, conversely
some parameters only display when EC Activation or Cascading Included are enabled.
