4.1.1 Output Rate
The Output Rate parameter defines the maximum possible output rate value of the transport-
stream and includes overhead.
In DSNG modules (Ellipse 3200), the actual output rate of the encoder can be set according to
either the Symbol Rate (from the Modulation menu) or the Output Rate (from the Transport
Stream menu). The actual rate is the rate last configured. This means that in DSNG modules (with
an IP or L-Band modulators), the actual output can be one of two settings:
■ Actual output rate is set according to the Symbol Rate (Modulation menu).
■ Actual output rate is set according to the Output Rate (Transport Stream menu).
The range is 350,000 to 160,000,000 bps. The Output Rate default value is 30,000,000 bps.
Front Panel:
4.1.2 Broadcast Standard
The Broadcast Standard parameter sets the stream broadcast standard to ATSC or DVB.
The available options are DVB and ATSC. The Broadcast Standard default is DVB.
Front Panel:
Output Rate
+30000000 [bps]
<00350000 - +70000000>
Broadcast Standard
1 ƒ DVB
2 ‚ ATSC
