Common Modulation Parameters
11.4.8 Roll-Off Factor
The Roll-Off Factor parameter sets the modulation roll-off value. The roll-off factor is responsible
for the quality of separation between partly overlapping satellite transmissions frequency
envelopes. Setting a large Roll-off value allows a larger portion of the relevant transmission to be
received, but also receives more irrelevant signals from the adjacent transmission. Setting a
smaller Roll-off value reduces the mount of irrelevant data from the adjacent transmission, but
also loses some information found in the edges of the relevant transmission envelope.
The available options are: 0.20, 0.25 or 0.35. The Roll-Off Factor default value is 0.35.
Front Panel
To set the Roll-Off Factor parameter on the front panel:
❖ Navigate Root > IF or L-Band Modulation > Roll-Off Factor.
Web Manager
To set the Roll-Off Factor parameter in the Web Manager:
❖ Select DSNG > MODULATOR AND UPCONVERTER (see Figure 11–2 or Figure 11–3).
Roll-Off Factor
ƒ 0.35
‚ 0.25
‚ 0.20
