Chapter 3 Ellipse Management
© 2013 Harmonic Inc. Harmonic All rights reserved. 65 Ellipse 3000 Release 3.0, Rev. B
Status Menu/Tab
3.5.1 Service and PID Table
The Service and PID table lists all audio and video elementary streams in the encoder. The table
details each elementary stream's information, such as: related service, PID number, rate, and
scrambling mode.
NOTE: This is a read-only table. Thus, on the front panel, selecting an elementary stream from the list returns
the screen one level up to the Status menu and does not display a new management screen.
Front Panel
To view the Service and PID table, on the front panel:
❖ Navigate Root > Status > Service and PID Table.
The available columns are:
■ Service – Displays the service period.
■ Element – Displays the name of the elementary stream related to the service.
■ PID – Displays the PID number of the elementary stream.
■ Rate – Displays the elementary-stream bit-rate value in Mbps.
■ Scram (Scrambling) – Displays whether or not the service is scrambled.
NOTE: In the Web Manager, the Element column is called Input and displays the video and the audio input for
the video and audio elements of the stream (see example in Figure 3–11).
The Web-Manager Services and PIDs table also displays the Res/Scheme column, displaying extra information
regarding the Service elementary stream:
■ For the video elementary-stream, the column specifies the video resolution value.
■ For the audio elementary-stream, the column specifies the audio coding scheme.
The elementary stream has three functions at statuses:
■ Active – Elementary stream is functional and enabled.
■ Ghost – Elementary stream is not active, but related to an active service. The rate is displayed as 0. Active
only when designated to Service.
■ Not Active – Elementary stream is not active nor related to any currently active services.
Service Element PID Rate
Scram
01 Enc_107 Video H.264 513 12.00M No
02 Enc_107 AUD2 4113 0.20M No
03 - - - Video MPEG-2 512 0.00M No
04 - - - AUD1 4112 0.00M No
