Chapter 11 DSNG Configuration
© 2013 Harmonic Inc. Harmonic All rights reserved. 321 Ellipse 3000 Release 3.0, Rev. B
Common Modulation Parameters
11.4.7 Operating Mode
The Operating Mode parameter sets the configuration and operation state for the Carrier and
Modulation Mode. Configuring the different Modulation and UpConverter parameters causes the
Carrier and Modulation Mode parameters to return to their default Off Value. Operating Mode
sets the reset mode of the Carrier and Modulation Mode.
The available options are:
■ C + M Auto Restore – After changing other Modulation parameters, Carrier (C) and Modulation
(M) Mode are automatically restored to recently configured and saved values.
■ C + M Man Restore – Carrier (C) and Modulation Mode (M) values are manually set. After
configuring other modulation parameters, Carrier and Modulation Mode are automatically set
to the default Off Value. The user must re-configure the values.
The Operating Mode default is C and M Man Restore.
Front Panel
To set the Operating Mode parameter on the front panel:
❖ Navigate Root > IF or L-Band Modulation > Operating Mode.
Web Manager
To set the Operating Mode parameter in the Web Manager:
❖ Select DSNG > MODULATOR AND UPCONVERTER (see Figure 11–2 or Figure 11–3).
Operating Mode
‚ C + M Auto Restore
ƒ C + M Man Restore
To Next Page
