Serial (Low Speed Data) Input Menu
9.4.3 LSD Rate Setup Menu
The Rate parameter sets the LSD value.
The available rate options are 9600, 14400, 19200, 38400, 57600 and 115200 (in bps). The Rate
default value is 9600 bps.
Front Panel
To set the Rate parameter on the front panel:
❖ Navigate Root > Configuration > Inputs > Serial Input > LSD > Rate.
Web Manager
To access the Serial Inputs LSD set-up menu in the Web Manager:
❖ Select Inputs > SERIAL INPUT > LSD.
9.4.4 LSD Timeout Setup Menu
The range is 0 to 320000 msec.
Front Panel
To access the Timeout parameter on the front panel:
❖ Navigate Root > Configuration > Inputs > IP Input > MPE > Timeout.
Web Manager
To access the Serial Inputs LSD set-up menu in the Web Manager:
❖ Select Inputs > SERIAL INPUT > LSD.
Rate
ƒ 9600 bps
‚ 14400 bps
‚ 19200 bps
‚ 38400 bps
Timeout
+000000 [msec]
<000000 - +320000>
