SDI Embedded Parameters
6.4.1 Group
Use the Group parameter to select the audio-channels group within the video channel.
To set the group on the front panel:
1. Navigate Root > Configuration > Audio > [Audio Channel#] > DD 5.1 Embedded Params >
Group.
2. Select the group.
To set the groups on the front panel for each Dolby Digital 5.1 channel set:
■ Navigate Root > Configuration > Audio > [Audio Channel#] > L/
R DD 5.1 Embedded Params > Group.
❖ Select the group.
■ Navigate Root > Configuration > Audio > [Audio Channel#] > C/
LFE DD 5.1 Embedded Params
> Group.
❖ Select the group.
■ Navigate Root > Configuration > Audio > [Audio Channel#] > LS/
RS DD 5.1 Embedded Params
>Group.
❖ Select the group.
The available options are a list of the available groups in the video channel.
To set the Group parameter in the Web Manager, Embedded parameters box:
1. Select Audio > Aud#.
2. Select the group in the Embedded parameters box.
Group
1 ƒ Group 1
2 ‚ Group 2
3 ‚ Group 3
4 ‚ Group 4
