Chapter 10 Unit Configuration
© 2013 Harmonic Inc. Harmonic All rights reserved. 287 Ellipse 3000 Release 3.0, Rev. B
SNMP Traps Sub-Menu
10.4.2.1 Set Destination IP
The Destination IP parameter defines the new trap-host entry by a new IP address.
To set the Destination IP parameter on the front panel:
❖ Navigate Root > Configuration > Unit > SNMP Traps > Add Entry > Destination IP.
The available value is of IP address type: xxx.xxx.xxx.xxx.
10.4.2.2 Add Entry
The Add Entry option allows creating a new entry in the Traps Destinations list. The new entry,
meaning host, is defined with the selected Destination IP address (see the previous section). This
option executes the Add Entry command, not leading to a new screen.
Once the new entry is displayed in the list, the user can access the Trap configuration menu and
set its other parameters (name, UDP port, and community).
To execute the Add Entry parameter, on the front panel:
❖ Navigate Root > Configuration > Unit > SNMP Traps > Add Entry > Add Entry.
10.4.3 Drop Entry Menu (front panel)
The Drop Entry menu allows deleting existing entries, meaning trap hosts, from the Traps
Destinations list.
To access the Drop Entry menu on the front panel:
❖ Navigate Root > Configuration > Unit > SNMP Traps > Drop Entry.
Destination IP
010.251.251.010
Drop Entry
1 Select Entry To Drop
New Host
2 Drop
