Chapter 1 Introduction
© 2013 Harmonic Inc. Harmonic All rights reserved. 17 Ellipse 3000 Release 3.0, Rev. B
Mechanical Structure
1.4.1.1 Introduction to Navigating the Front Panel
Top Line
The top line indicates the menu name. Up, Up/Down, and Down are displayed on the
top-right corner and indicate that up/down scrolling is possible.
Numbered Items
The screen default display consists of up to four items simultaneously. Scroll up or down the list
using the UP and Down keys.
Options
The currently selected option is highlighted and displayed in reverse with white characters on a
black background.
Press <ESC> key to abort the selection or to return to the parent menu.
Press <Enter> key to select the highlighted item.
1.4.2 Ellipse Rear Panel
The Ellipse rear panel contains all required input and output connectors for the encoder
operation. The AC connector and power switch are also located on the rear panel. The different
Ellipse Series modules present various rear panels, as requirements of inputs and connectors vary.
The following images illustrate examples of rear panels. The related tables describe the
connectors on the panel.
