Harmonic Ellipse 3000 - LSD Activation Menu; LSD PID Setup Menu

Chapter 9 Input Interface Configuration
© 2013 Harmonic Inc. Harmonic All rights reserved. 255 Ellipse 3000 Release 3.0, Rev. B
Serial (Low Speed Data) Input Menu
9.4.1 LSD Activation Menu
The options are:
■ Disabled
■ Enabled
Front Panel
To access the Activation menu on the front panel:
❖ Navigate Root > Configuration > Inputs > Serial Input > LSD > Activation.
Web Manager
To access the Serial Inputs LSD set-up menu in the Web Manager:
❖ Select Inputs > SERIAL INPUT > LSD.
9.4.2 LSD PID Setup Menu
The range is 0X20 to 0X1ffe (HEX).
Front Panel
To access the PID menu on the front panel:
❖ Navigate Root > Configuration > Inputs > Serial Input > LSD > PID.
Web Manager
To access the Serial Inputs LSD set-up menu in the Web Manager:
❖ Select Inputs > SERIAL INPUT > LSD.
Activation
ƒ Disabled
‚ Enabled
PID
0X0576 [HEX]
<+0X20 - +0X1ffe>
