M-SPTS Sub-Menu/Tab
4.3.2.2 Advanced Stream Functions
The Advanced Menu allows the user to set the various Encoder IP Output parameters.
The M-SPTS Advanced features enabled for managing are:
■ FEC Activation – activates/deactivates the FEC error correction function for the stream.
■ FEC dimension – The options are: 1D and 2D. The default is 2D. When an upgrade has been
performed and FEC was already activated then the default is 1D.
■ FEC Column Number – sets the FEC error correction column location for the stream.
The range is 01 to 20. (The maximum matrix size is 100.)
■ FEC Row Number – sets the FEC error correction row location for the stream.
The range is 04 to 20. (The maximum matrix size is 100.)
■ Cascading Included – enables/disables the cascading ability of the stream.
Front Panel
To set the M-SPTS stream advanced parameters on the front panel:
❖ Navigate Root > Configuration > Transport Stream > M-SPTS > Transports List >
[Stream Name] > Advanced.
Web Manager
To access the stream advanced features menu in the Web Manager:
❖ Select Transport > M-SPTS > [Stream Name] and go to the Advanced box.
Advanced
1 FEC Activation
Disabled
2 FEC dimension
2D
3 FEC Column Number
06
4 FEC Row Number
06
5 Cascading Included
Disabled
