Chapter 10 Unit Configuration
© 2013 Harmonic Inc. Harmonic All rights reserved. 291 Ellipse 3000 Release 3.0, Rev. B
Alarm Sub-Menu/Tab
Management Port Disconnected Management port address is not valid
Data Port disconnected Data port address is not valid
BOOTP failed Wrong BOOTP parameters for encoder
Wrong Boot File name BOOTP parameters not suitable for encoder
TFTP Failed Failure to connect to the TFTP server.
ZAP Failed NMX ZAP failed
AP_EDH Error on Input You can enable or disable this alarm. This alarm is active with CRC error
for the Active Picture
FF_EDH Error on Input You can enable or disable this alarm. This alarm is active with CRC error
for the Full Field
Software Upgrade Failure Software upgrade failed due to hardware
Other Trafic On Port Other traffic on the port
Duplicate Sgid The alarm is triggered by a primary device if another primary device in the
group is detected with same SGID.
For 1:1 scheme the SGID is not user configurable so this alarm is triggered
if more than one primary is configured with the same group ID.
Solution:
Check the other primary devices and find the one with the same Group ID
and same SGID.
For 1:1, find two primary devices with the same GID.
Redundancy Mode Mismatc Redundancy mode mismatch.
Backup Device is Active The alarm is triggered by a backup device when it is active.
Solution:
Swap between the primary and the backup.
Primary Device is not Active The alarm is triggered by a primary device when it is inactive.
Solution:
Check what caused the primary to be inactive, fix the problem then switch
back.
Fail to Sync Configuration This alarm is triggered by a backup device when it fails to get the primary’s
configuration.
Solution:
Check why the backup can’t get the configuration. It can be due to a
primary problem, primary connectivity (the sync can only be on the
management network) or backup connectivity.
No Available Backup This alarm is triggered by a primary Ellipse when there is no available
backup Ellipse in the same group with a valid configuration and without
DRT.
Solution:
Check the backup device for
■ Connectivity
■ A valid configuration
If it is already active
