Chapter 11 DSNG Configuration
© 2013 Harmonic Inc. Harmonic All rights reserved. 301 Ellipse 3000 Release 3.0, Rev. B
L-Band Modulator Parameters
Front Panel
To access the L-Band Modulation and Up-Converter menu on the front panel:
❖ Navigate Root > L-Band Modulation & Up-Converter.
L-Band Modulation & Up-converter
Carrier
On
L-Band Power
-20
Reduced L-Band Power
-13.0
Modulation on/off
Off
Symbol Rate
10000000
TX RF Freq
014950000
RF Conv. LO Freq
014000000
L-Band Frequency
0950000
Spectrum Inversion
Direct
Modulation Scheme
DVB-S2
FEC and Modulation
QPSK 2/3
Frame Length
64800 bits
Operating Mode
C and M Restore...
Roll-Off Factor
0.35
Pilot Mode
Off
Remote Power 24VDC
Off
10MHz Clock
Off
