Ellipse Management Interfaces
Top Line
The top line indicates the menu name. Up, Up/Down, and Down are displayed on the top-
right corner and indicate that up/down scrolling is possible.
Numbered Menu Items
A list of numbered entries relevant to the menu and their current value. The information provided
in each entry is:
Left-aligned column displays a numbered list of parameters.
Right-aligned column displays the parameter’s value.
❑ Editable parameters have a pencil icon next to them.
❑ Parameters without the pencil icon are read only.
The screen default display consists of up to four entries simultaneously. When more than four
entries are enabled, the user can scroll up or down the list using the UP and Down keys.
Options
The currently selected option is highlighted and displayed in reverse with white characters over a
black background.
Press <ESC> to abort the selection or to return to the menu’s previous level.
Press <Enter> to select the highlighted editable option (editable options are marked with a pencil
icon ); a parameter-editing screen displays.
Table Menu Screen
The Table menu screen displays information about the menu’s parameters in a table format.
Configurable tables enable to select an item from a chosen table and access Edit Menu screen for
setting the entry values:
Top Line
The top line indicates the headers for each column in the table. Up, Up/Down, and Down
are displayed on the top-right corner and indicate that up/down scrolling is possible.
Service Element PID Rate Scram
01 Service-1 Audio-10x0064 0.21M No
02 Service-1 Video-10x006c 4.59M No
03 Servcie-2 Video-20x006d 4.62M No
04 Service-2 Audio-20x0065 0.21M No
05 --- Audio-30x0066 0.21M No
06 --- Audio-80x006b 0.21M No
To Next Page
