15
1.3 Names and Functions of Parts
Menu Display Sequence
Settings made from the Menu Display are saved internally when you
press ENTER or SHIFT to return to the Measurement Display.
Temperature
Correction/Conversion
Selection Display
❖ (Page 58)
Zero-Adjust Clear
Setting Display
❖ (Page 41)
Interface
Selection Display
❖ (Page 99)
Self-Calibration
Setting Display
❖ (Page 66)
Measurement Terminal
Selection Display
❖ (Page 26)
BIN/BNC Output
Selection Display
❖ (Page 82)
Measurement Fault Output
Timing Setting Display
❖ (Page 82)
Key Beeper
Setting Display
❖ (Page 67)
Line Frequency
Setting Display
❖ (Page 25)
Reset Display
❖ (Page 73)
(SHIFT Lamp lit)
The Menu display appears.
(Main Display)
Adjustment Display
The Adjust Display is intended for use
only by a service technician.
Accuracy cannot be guaranteed if the
user makes adjustments with this display.
The up/down RANGE key changes the setting shown
on the Sub Display.
Press to return to previous display.
Press twice
To Next Page
