5.2 BIN Measurement Function
10
Connect to a test object, and judge the measured value.
The measured value appears on the Main Display, and the decision
result appears on the Sub Display.
Measured value
Decision result
(BIN0: in range, BIN2: out of
range)
❖ Interpreting decision
results:(Page 56)
Upper and lower thresholds are stored as the actual entered digits,
independent of measurement function and range.
When the measurement function or range is changed, the absolute
value represented by the entered digits changes accordingly.
Example: To set the lower threshold to 3.8 Ω in the 20 Ω range, enter
038000. If you now switch to the 200 Ω range, the lower threshold
becomes 38 Ω.
