7.2 Printer Connection
90
Paper insertion slot
Cut the paper
horizontally.
Note the paper orientation!
OK
Load the recording paper into the
9670 PRINTER.
Handling and Storing Recording Paper
The recording paper is thermally and chemically sensitized. Observe the following
precautions to avoid paper discoloration and fading.
Avoid exposure to direct
sunlight.
Do not store thermal
paper above 40°C or 90%
RH.
Avoid stacking with wet
Diazo copy paper.
Avoid exposure to volatile
organic solvents like
alcohol, ethers and
ketones.
Avoid contact with
adhesive tapes like soft
vinyl chloride and
cellophane tape.
Loading Recording Paper
9670 PRINTER
• Store thermal paper where its temperature will not exceed 40°C.
• The paper will deteriorate if exposed to light for a long time, so do
not remove rolls from their wrappers until ready to use.
• Make photocopies of recording printouts that are to be handled or
stored for legal purposes.
To Next Page
