Hioki 8807-01 User Manual

193
_____________________________________________________________________
10.1 Environment Screen (SYSTEM)
______________________________________________________________
Flashing cursor
Settable
Non-settable
10.1.8 Display Color
Serves to set the display color.
Screen display color can be selected from colors 1 to 16.
Procedure
Environment Screen
1. Press the
SYSTEM
button to display the Environment
Screen.
2. Move the flashing cursor to
Display Color
and select a color
using the
buttons.
When colors 1 to 6 are selected, the screen displays are
shown in colors. The settable items are displayed in yellow,
and non-settable items are displayed in gray.
When colors 7 to 16 are selected, the screen displays are
shown in single color. As shown in the screen below,
settable items are underlined (__) and non-settable items are
displayed as double lines(__
).
