14.1 General Specifications
______________________________________________________________
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
AP
P
IND
Measurement
functions
Memory recorder (High-speed data saving)
Recorder (Real time recording)
RMS recorder (For commercial power supplies)
Harmonic wave analysis*
1
Number of channels
(maximum)
8807-01, 8807-51: 2 analog channels
+
8logicchannels
8808-01, 8808-51: 4 analog channels
+
8logicchannels
(The logic channels are standard equipment, common
ground with main product)
Memory capacity
(Harmonic wave
analysis)
*
1
8807-01, 8807-51:
8808-01, 8808-51:
256 K words/channel (CH1)
128 K words/channel (CH1, CH2)
256 K words/channel (CH1)
128 K words/channel (CH1, CH2)
64 K words/channel (All)
For waveform storage: analog 12 bit
X
16 Kwords/ch
For analysis results: analysis results 32 bit X 96 Kwords
Maximum sampling
rate
400 kS/s (all channels simultaneously)
Time axis accuracy
0.01% (difference between grid and actual time)
External terminals
External trigger input, trigger output, GND
Time functions
Auto calendar with automatic leap year,
24 hour clock
Backup battery and
lifetime
Used for waveform, clock and to preserve waveforms
and settings, at least 5 years
(reference value at 25
,77 )
Location for use
Max. 2000 m (6562 feet) height, indoors
Chapter 14
Specifications
14.1 General Specifications
Basic specifications
(*1): 8807-51, 8808-51 only
