3.6 Measurement Start and Stop
______________________________________________________________
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
APP
IND
START
button
Pressing this button starts measurement.
The LED on the upper part of the switch
lights green during measurement.
STOP button Pressing this button stops the measurement.
START
STOP
button
Manual trigger
When Manual Trigger is enabled (ON) on
the Trigger Screen, the trigger is activated
by pressing this button during the trigger
wait state.
Pressing the
button with the flashing
cursor aligned with a setting item displays
the setting items.
CARD button Using PC card:
Displays the File Screen.
Using Fax/modem card:
Displays the Fax&Modem Screen.
CARD
3.6 Measurement Start and Stop
3.7 Other Buttons Operation
The measurement start/stop operation is separately
determined by each measurement function.
For details, refer to "Start and Stop Operation," which
explains each measurement function.
