12.2 Using the PC Card Slot
______________________________________________________________
CAUTION
If a PC card is inserted upside down, backwards, or in the
wrong direction, the PC card or the product may suffer
damage.
Do not remove the PC card while the PC card unit is
operating.
Before shipping the product, always remove the PC card
and close the cover.
Insertin
g
a PC Card
Removin
g
a PC Card
E
j
ect button
12.2 Using the PC Card Slot
Before using a new PC Card, it must be initialized. For
details, refer to Section 12.3.5.
PC Card Insertion and Removal
Open the cover and insert the
PC Card with the arrow
facing up and in the direction
of the PC card slot, as far as
it will go.
Press the Eject button and
pull the PC Card out.
Always close the cover when
the PC card is not used.
