14.6 Harmonic Wave Analysis Function
______________________________________________________________
Types of analyses
When voltage (current) input is set
(1) Harmonic effective value (Bar graph, numerical
value)
(2) Harmonic percentage content (Bar graph, numerical
value)
(3) Harmonic phase (Bar graph, numerical value)
(4) Synthesis effective value (Numerical value)
(5) Synthesis distortion rate - F (Numerical value)
(6) Synthesis distortion rate - R (Numerical value)
When single-phase two-wire, single-phase three-wire, or
three-phase three-wire is set (not available when using
the 3283 to 3285)
(7) Harmonic active power (Bar graph, numerical
value)
(8) Harmonic power percentage content (Bar graph,
numerical value)
(9) Harmonic power phase (Vector graph, numerical
value)
(10) Active power (Numerical value)
(11) Reactive power (Numerical value)
(12) Apparent power (Numerical value)
(13) Power factor (Numerical value)
Waveform
enlargement/compr
ession factor
x100, x50, x20, x10, x5, x2, x1, x1/2, LOG*
1
Print type
Waveform, graph, list
Auto print
ON/OFF
Manual print
Available
Scaling function
Available
(1) When using a Hioki clamp, the unit of
measurement is automatically set to "A" once the
model name has been selected.
(2) PT/CT ratio can be set.
(3) When using a clamp from another manufacturer, the
unit of measurement is automatically set to "A" once
the voltage/current conversion ratio has been input.
14.6.2 Instantaneous Analysis Functions
Update cycle: 1s
(*1): Excluding for vector graph.
