236
_____________________________________________________________________
12.1 PC Card
______________________________________________________________
12.1 PC Card
(1) Saving and Loading Measurement Data (binary format)
Measurement data is saved in binary format so that, when
needed, it can be loaded back into the product for data
analysis and printing.
Harmonic wave analysis data that was saved by the 8807-
51, 8808-51 cannot be loaded into the 8807-01, 8808-01.
(2) Saving Measurement Data (text format)
Measurement data can be saved in text (CSV) format. The
saved data can be thinned, and can be used directly by
many word processing and spreadsheet applications, but the
text format cannot be read back into the product.
(3) Automatic Saving of Measurement Data
Measurement input data can be automatically saved to a PC
Card.
(4) Partial Saving of Measurement Data (binary and text
formats)
Measurement data to be saved to the PC Card can be
limited to that between the A and B cursors.
(5) Saving and Loading Setting Data
Settings such as the time axis and voltage axis range are
saved and loaded when needed to allow duplicating
measurement conditions.
(6) BMP (bitmap) Data Saving
Screen images can be saved in bitmap (BMP) format.
(7) Auto Setup
Settings can be loaded automatically when power is turned
on by creating a file named STARTUP.SET in the root
directory.
To Next Page
