4.9 Recording Using Specific Conditions (Trigger Function)
112
Types of trigger for which [Timing] can be set
îž”: Selectable, X: Not selectable
Timing
Start Stop
Analog input signal CH1 to CH4
îž” îž”
Logic input signal LA1 to LA4, LB1 to LB4
îž” îž”
External trigger EXT.TRIG
îž” îž”
Interval trigger Fixed interval recording
îž”
X
• The timing settings cannot be configured for the High-speed Function.
• If [Timing] is set to [Stop] (or [Start/Stop]) and the trigger is not
applied during data acquisition for the set recording time portion after
measurement starts, measurement ends at the point in time that the
data for the recording time portion has been acquired.
• When [Timing] is set to [Stop] and [Repeat] is set to [Single], mea-
surement ends after the stop condition is met. However, measure-
ment will be resumed if [Repeat] is set to [Repeat].
• When [Timing] is set to [Start/Stop], the instrument first waits until
the trigger of the [Start] condition is applied.
