13.2 High-speed Function
235
Chapter 13 Specifications
13
Basic Specifications
13.2 High-speed Function
Timebase
100, 200, 500 μs/div
1, 2, 5, 10, 20, 50, 100 ms/div
Time axis resolution 100 points/div (80 points/div when printing with printer/div)
Sampling period 1/100th of timebase
Recording length
5 to 10000div Settable in 5-division steps
(Also stores one previous measurement after measurement starts)
Data types Selectable from instantaneous values and effective values
Display Screen
Waveform display
Simultaneous waveform and trigger setting display
Simultaneous waveform and setting display
Simultaneous waveforms and numerical calculation results display
Waveform and A/B cursor values displayed at the same time
Screen settings Single, Dual, Quad, X-Y Dots, X-Y Line
Waveform compres-
sion and magnifica-
tion
Horizontal axis (time axis):
x10, x5, x2, x1, x1/2, x1/5, x1/10, x1/20,
x1/50, x1/100, x1/200, x1/500, x1/1000, x1/2000
Vertical axis (voltage axis): Differs depending on display method
setting.
• When set by position:
Magnification: x20, x10, x5, x2, x1, x1/2, x1/5, x1/10
Position: Set -50 to 150% (when magnification x1)
• When set by upper and lower limits: Set the upper and lower lim-
its.
The display is as follows when the measurement value is over the
set range.
• "OVER" when over on + side
• "-OVER" when over on - side
Waveform scrolling
Scrolling possible in time axis direction only for data portion stored
in internal buffer memory
(Possible both during measurement and after measurement)
<</ >> These keys make large jumps
Auto save
Selectable from Off, waveform, CSV, numerical calculation, wave-
form + numerical calculation, and CSV + numerical calculation
When data has been acquired for the specified recording length
portion, all data is saved simultaneously.
To Next Page
