13.5 Monitor Functions
243
Chapter 13 Specifications
13
Schedule function
Up to 10 measurement start and stop conditions can be set.
1. Specified day
• The start time and stop time (year/month/day/hour/minute) can
be set.
• The setting conditions for performing a scheduled operation can
be set.
2. Fixed time
• The start day (specify daily, Monday to Friday, Monday to Satur-
day, or days every week) can be set.
• The start time and stop time (hour/minute) can be set.
• The setting conditions for performing a scheduled operation can
be set.
13.5 Monitor Functions
Refresh rate 0.5 s
Display items
Numerical values and measurement waveform of instantaneous
values or effective values
(The number of divisions of the displayed waveform differs
depending on the gauge setting. The number of divisions is five for
Off or ALL2, and three for a setting other than that.)
The Monitor screen is displayed when the MONITOR key is
pressed.
The Monitor screen can also be displayed when the instrument is
waiting for a trigger
No. of display digits 5
Range used Same as measurement range
Accuracy
• Instantaneous value measurement: ±0.5% f.s. (after zero adjust-
ment)
• Effective value measurement: ±1.5% f.s. (30 Hz to 1 kHz), ±3%
f.s. (1 kHz to 10 kHz)
(Guaranteed accuracy range: 10% to 100% of full scale)
Print function
The values shown in numerical display can be printed by pressing
the PRINT key
13.6 Setting Wizard Function (PRESETS)
Selection options
1. Basic Measurement Guide
2. Measurement Example Guide
3. Load Settings from Memory
To Next Page
