7.5 Various Print Settings
171
Chapter 7 Printing
7
You can add a grid to a waveform and print the channel number or a comment and
other information. The [Print] tab is added to the settings screen when you connect
a printer.
The information printed for the horizontal axis is the same as that of the screen dis-
play ( p. 201).
To print automatically after measurement, configure the setting before measure-
ment.
See: "4.8 Setting Automatic Printing" (p. 108)
You print the channel number or a comment together with
the waveform.
7.5 Various Print Settings
Printing the Channel Number or Comment (Channel Marker)
CH1
1
2
Select from the setting options of
[Channel marker].
Setting options (∗. default setting)
Off Does not print a channel number and comment.
Channel No.∗ Prints the channel number.
Comment Prints a comment. Set a comment in the [CH] screen.
See: "4.10 Entering Comments and Titles" (p. 128)
(Open/confirm the setting information.)
Select the [Print] screen.
• If the waveform to be printed is short, the comment may not be
printed.
• In the case of X-Y display, the channel markers are not displayed.
