Hioki MEMORY HiCORDER MR8880 User Manual

4.9 Recording Using Specific Conditions (Trigger Function)
114
Block Diagrams of Trigger Application Conditions (AND/OR)
AND
OR
CH1
CH2
CH3
CH4
1
2
3
4
LA
1
2
3
4
LB
AND
OR
START/
STOP
CH1
CH2
CH3
CH4
1
2
3
4
LA
1
2
3
4
LB
OR
OR
START/
STOP
When the [OR] trigger application condition is selected, the change point
(edge) when each trigger source changes from unmet to met is detected.
External trigger
Interval
In accordance with the logic trig-
ger application condition.
External trigger
Interval
In accordance with the logic trigger
application condition.
When the [AND] trigger application condition is selected, the state in which
all of the trigger sources are met is detected.
