13.3 Real-time Function
238
Remove external
media
The storage media can be removed during real-time saving.
(When replacing external storage media, replace it within 20 sec-
onds when the recording interval is set to 100 µs.)
(Removal procedure)
Press the storage media eject button on the screen.
A message appears when the storage media becomes able to be
ejected.
When reinserting the storage media, save the data retained in
internal buffer memory while the storage media was not inserted
to a separate file.
Real-time printing
Selectable from Off and On (limited by time base, no trace print-
ing)
Printing simultaneously with acquiring of waveforms possible.
However, only when the time base is slower than 1 s/div.
Partial printing using cursors A and B is not possible during real-
time printing.
Manual print
Printing with the printer is performed in the measurement stop
state each time the PRINT key on the MR9000 Printer Unit is
pressed.
(Only measurement data stored in internal buffer memory is
printed.)
Partial printing
Part between cursors A and B printable
(When the PRINT key on the MR9000 Printer Unit is pressed, a
screen for selecting printing of all data or part of data is displayed
to enable the print range to be selected.)
