5.2 Changing the Recording Settings
77
Chapter 5 Changing Settings (as necessary)
5
Sets the TIME PLOT interval (recording interval).
See:"Key operation during configuration" (p.75)
The time series graph recording time varies with the recorded parameters and TIME PLOT interval setting.
See:"Recording Items" (p.76)
Recording times (reference value) for a Z4001 SD Memory Card 2 GB
(Repeat Record: 1 week, Repeat Number: 55 times)
• Figures indicate the amount of recording time after the SD memory card has been initialized.
• Recording times do not account for event data and screen copy data. Recording times may be short-
ened when event data and screen copy data are stored on the card.
• Recording times are not dependent on connections.
• When repeated recording is set to [O
FF], the maximum recording time is 35 days.
• When repeated recording is set to [
1 Day], the maximum recording time is 366 days.
• When repeated recording is set to [
1 Week], the maximum recording time is 55 weeks.
• Harmonics order data is not saved for [Power], but
it is saved in THD.
Outputs the display image to the SD
memory card at the
set screen copy interval.
See:"Key operation during configuration" (p.75)
TIME PLOT Interval
Setting Contents:( ∗ : Default setting)
1/ 3/ 15/ 30 second(s), 1∗/ 5 /10/ 15/ 30 minute(s) ,
1/2 hour(s), 150/180/1200 cycle
The 150 cycle (50 Hz) and 180 cycle (60 Hz) settings provide the TIME PLOT intervals
required for IEC 61000-4-30-compliant measurement. You can select 150 cycles (mea
-
surement frequency of
50 Hz), 180 cycles (60 Hz), or 1200 cycles (400 Hz).
TIME PLOT interval
Recording parameter setting
All data
(Saves all data)
Power and Harmonic
(Saves RMS values and
harmonics)
Power
(Saves RMS values only)
1 second 16.7 hours 23.4 hours 13.2 days
3 seconds 2.1 days 2.9 days
39.7 days
15 seconds 10.4 days 14.6 days 198.4 days
30 seconds 20.9 days 29.3 days
55 weeks
1 minute 41.7 days 58.6 days 55 weeks
5 minutes 208.6 days 292.8 days
55 weeks
10 minutes 55 weeks 55 weeks 55 weeks
15 minutes 55 weeks 55 weeks
55 weeks
30 minutes 55 weeks 55 weeks 55 weeks
1 hour 55 weeks 55 weeks
55 weeks
2 hours 55 weeks 55 weeks 55 weeks
150/180 /1200 cycle
(Approx. 3 sec) 2.1 days 2.9 days 39.7 days
When the memory is full
The PQ3198 stops recording data to the SD memory card.
Measuring for an extended period of time.
If repeated recording is enabled and the recording count set, the instrument can make measure-
ments for up to 55 weeks.
See: Long-term measurements over 1 month or longer: Enable repeated recording (see "Repeat Record" (p.79)).
Screen copy interval
Setting Contents:( ∗ : Default setting)
OFF∗/5/ 10/ 30 minute(s)/ 1/ 2 hour(s)
