Appendix 2 Measurement Data Saving Format
A3
Appendix
Harmonic Measurement Items
Harmonic Frequency HFREQ
(n=0)
nth order voltage
Level HU1Ln
(n: order)
Content HU1Dn
Phase angle HU1Pn
... to
Level HU4Ln
Content HU4Dn
Phase angle HU4Pn
nth order current
Level HI1Ln
Content HI1Dn
Phase angle HI1Pn
... to
Level HI4Ln
Content HI4Dn
Phase angle HI4Pn
nth order power
Level HP1Ln
Content HP1Dn
Phase angle HP1Pn
... to
Level HP4Ln
Content HP4Dn
Phase angle HP4Pn
Level HP12Ln
Content HP12Dn
Phase angle HP12Pn
Level HP34Ln
Content HP34Dn
Phase angle HP34Pn
Level HP123Ln
Content HP123Dn
Phase angle HP123Pn
(n=1 to 100) ... ... ... (n: order)
Noise Measurement Items
Noise
Voltage UNf01 UN01 to UNf10 UN10
Current INf01 IN01 to INf10 IN10
