Hirschmann RS20 User Manual

Entering the IP Parameters
44
2.5 System configuration via BOOTP
Basic Configuration
Release 6.0 07/2010
Figure 14: Flow chart for the BOOTP/DHCP process, part 2
Load transferred
config file
No
Yes
Load remote
configuration from
URL of DHCP?
No*
Yes
Start tftp process
with config
file URL of DHCP
tftp
successful?
Save transferred
config file local
and set
boot configuration
to local
2
Loading of
configurations data
is complete

Hirschmann RS20 Specifications

General

Mounting	DIN Rail
Operating Temperature	-40°C to +70°C
Protection Class	IP30
Switching Technology	Store-and-Forward
Product Type	Industrial Ethernet Switch
Port Details	10/100 Mbps Ethernet ports
Switching Capacity	3.2 Gbps
MAC Address Table	8k
Management	Web, SNMP
Redundancy	MRP
Ports	8 or 16
