sure the battery is fully charged) with the throttle
wide-open until the compression reading on the
gauge stabilizes.
NOTE:
When cranking the engine, ground the spark plug
lead to prevent sparking.
4. Install:
·
spark plug
18 Nm-20Nm (1.8 m · kg, 13 ft · lb)
CHECKING THE ENGINE OIL LEVEL
1. Place the vehicle on a level surface
2. Check:
·engine oil level
Oil level should be between the ②engine oil
mirror maximum and minimum marks.
Oil level low
Add oil to the proper level.
Recommended oil
Follow the left chart.
NOTE:
Recommended oil classification:
API Service “SE”, “SF”, “SG” type or equivalent
(e.g. “SF—SE—CC”, “SF—SE—SD” etc.)
NOTE:
Do not allow foreign material to enter the
crankcase.
3. Stop the engine and check the oil level again
NOTE:
Wait a few minutes until the oil settles before
checking the oil level.
NOTE:
Never remove the dipsti]ck just after high speed
operation because the heated oil could spurt out.
Wait until the oil cools down before removing the
dipstick.
